BSC-A8 Adjustable Speed Label Rewinder Two-way Automatic
The BSC A8 6.5 Inch Label Rewinder is a heavy-duty, industrial-grade accessory designed to seamlessly collect and roll labels as they exit your barcode printer. Built for continuous operation, this rewinder eliminates the chaotic pile-up of printed media, ensuring that large batch jobs remain organized, clean, and ready for immediate application.
Whether you are printing thousands of daily logistics tracking labels or detailed inventory tags, this automated take-up system provides the perfect finishing touch to your thermal printing workflow.
Streamlined Post-Print Label Management
BSC A8 6.5 Inch Label Rewinder Designed to accommodate media up to 150mm (approximately 6 inches) wide. this device is the ideal companion for standard and wide-format industrial thermal printers. Instead of manually gathering long strips of paper, the rewinder automates the collection process. It utilizes an intelligent tension arm that dynamically adjusts to your printer’s output speed. Consequently, this creates a tight, uniform roll that prevents media damage, mitigates the risk of workplace hazards caused by trailing paper, and saves hours of manual labor in busy environments.
Technical Specifications : BSC A8 6.5 Inch
| Specification | Details |
| Model | BSC A8 (Label Take-Up Rewinder) |
| Maximum Label Width | 150 mm (Approx. 6 inches) |
| Maximum Roll Diameter | Up to 230 mm (9 inches) |
| Rewind Speed | Up to 10 inches per second (Adjustable) |
| Rewind Direction | Bi-directional (Face-in / Face-out) |
| Core Compatibility | Adjustable core holder (Supports 1″, 1.5″, and 3″ cores) |
| Power Supply | AC 110V/220V, 50/60Hz |
Core Features and Functionality: Label Rewinder
- Dynamic Speed Synchronization: The built-in mechanical tension arm automatically senses the printer’s ejection speed and halts when printing stops, preventing tearing or excessive pulling on the printer’s internal mechanisms.
- Bi-Directional Winding: Capable of winding labels facing inward (CSI) or outward (CSO), providing maximum flexibility to match the requirements of specific automatic label applicators.
- Heavy-Duty Construction: Built with a solid, anti-static metal chassis to absorb vibration, ensuring stability and long-term durability on the production floor even during rapid, 24/7 operations.
- Versatile Core Holder: Features an adjustable expansion shaft that easily adapts to various standard core sizes, eliminating the need for separate adapters.
- Wide Media Capacity: Flawlessly handles media up to 150mm wide, making it highly versatile for standard 4×6 shipping labels, wide chemical drum labels, and multi-column jewelry tags.
